| SIZE MM |
A MM |
B MM |
D MM |
d MM |
W MM |
WLL(KGS) KG |
WEIGHT 100 PCS/KG
|
| 5 | 10 | 20 | 5 | 5 | 16 | 80 | 1.9 |
| 6 | 12 | 24 | 6 | 6 | 20 | 100 | 3.4 |
| 8 | 16 | 32 | 8 | 8 | 24 | 200 | 7 |
| 10 | 20 | 40 | 10 | 10 | 32 | 320 | 13 |
| 12 | 24 | 48 | 12 | 12 | 38 | 520 | 26 |
| 16 | 32 | 64 | 16 | 16 | 56 | 800 | 50 |
| 20 | 40 | 80 | 20 | 20 | 66 | 1100 | 80 |
| 22 | 44 | 88 | 22 | 22 | 74 | 1500 | 130 |
| 25 | 50 | 100 | 25 | 25 | 80 | 2100 | 200 |
| 28 | 56 | 112 | 28 | 28 | 94 | 3000 | 300 |
| 32 | 64 | 118 | 32 | 32 | 104 | 3500 | 430 |
| 38 | 76 | 152 | 38 | 38 | 126 | 5000 | 700 |
| 45 | 90 | 180 | 45 | 45 | 150 | 7000 | 1250 |
| 50 | 100 | 200 | 50 | 50 | 166 | 8000 | 1750 |
