SIZE
|
WEIGHT (KG)
|
WLL/T(5:1) |
D
|
Φ
|
L
|
|
| WLL 45° | Vertical load | |||||
| M6 | 0.05 | 0.05 | 0.07 | 36 | 20 | 36 |
| M6 | 0.05 | 0.095 | 0.14 | 36 | 20 | 36 |
| M10 | 0.09 | 0.17 | 0.23 | 45 | 25 | 45 |
| M12 | 0.16 | 0.24 | 0.34 | 54 | 30 | 53 |
| M14 | 0.2 | 0.32 | 0.46 | 63 | 35 | 62 |
| M16 | 0.24 | 0.5 | 0.7 | 63 | 35 | 62 |
| M18 | 0.34 | 0.65 | 0.83 | 72 | 40 | 71 |
| M20 | 0.36 | 0.83 | 1.2 | 72 | 40 | 71 |
| M22 | 0.58 | 1.05 | 1.5 | 81 | 45 | 81 |
| M24 | 0.72 | 1.27 | 1.8 | 90 | 50 | 90 |
| M27 | 0.7 | 1.83 | 2.5 | 90 | 50 | 90 |
| M30 | 1.32 | 2.6 | 3.6 | 108 | 60 | 109 |
| M33 | 1.3 | 3.2 | 4.5 | 108 | 60 | 109 |
| M36 | 2.08 | 3.7 | 5.1 | 126 | 70 | 128 |
| M39 | 2.02 | 4.3 | 6 | 126 | 70 | 128 |
| M42 | 3.11 | 5 | 7 | 144 | 80 | 147 |
| M45 | 3.04 | 5.5 | 7.5 | 144 | 80 | 147 |
| M48 | 5.02 | 6.1 | 8.6 | 166 | 90 | 168 |
| M52 | 4.95 | 7.3 | 9 | 166 | 90 | 168 |
| M56 | 6.69 | 8.3 | 11.8 | 184 | 100 | 187 |
| M64 | 9.3 | 11 | 16 | 206 | 110 | 208 |
