| Size | A | B | D | H1 | H2 | H3 | Design | Approx. Inside Width | AC226 Cost | AC226 Weight |
| 2mm | 4.37 | 9.89 | 3 | 17.5 | 9.15 | 4.26 | 100 | 7.01 | 1.4 | 3.36 |
| 3mm | 5.53 | 9.56 | 4 | 20 | 9.67 | 5.46 | 100 | 11.08 | 1.6 | 3.6 |
| 4mm | 6.49 | 11.65 | 4 | 21.6 | 9.85 | 4.01 | 100 | 12.14 | 1.8 | 3.9 |
| 5mm | 7.25 | 16.12 | 5 | 27.5 | 10.41 | 3.98 | 100 | 12.65 | 2 | 4.48 |
| 6mm | 7.12 | 17.62 | 6 | 32.5 | 11.82 | 5.95 | 100 | 29.05 | 2.4 | 6 |
| 8mm | 9.54 | 20.02 | 6 | 34 | 15.44 | 5.83 | 100 | 36.14 | 3.2 | 7.2 |
| 10mm | 11.24 | 22.71 | 8 | 44.1 | 16.57 | 5.95 | 100 | 62.23 | 5.6 | 10.2 |
| 12mm | 15.88 | 29.35 | 10 | 51 | 17.99 | 6.61 | 50 | 118.09 | 9 | 17.6 |
| 14mm | 15.66 | 29.35 | 10 | 56 | 21.82 | 8.34 | 50 | 140.46 | 13.4 | 19 |
| 16mm | 18.01 | 29.55 | 12 | 65 | 24.69 | 8.43 | 20 | 201.06 | 14 | 20.8 |
| 18mm | 20.07 | 29.85 | 12 | 80 | 29.72 | 9.65 | 20 | 258.46 | 18.2 | 25.5 |
| 20mm | 22.94 | 32.44 | 12 | 73 | 30.82 | 10.51 | 20 | 247.56 | 19 | 26.6 |
| 22mm | 24.12 | 32.56 | 12 | 87.3 | 32.44 | 11.87 | 10 | 346.87 | 28 | 39.2 |
| 24mm | 26.13 | 33.41 | 12 | 76 | 33.76 | 12.87 | 10 | 341.95 | 29 | 40.6 |
| 26mm | 27.36 | 54.12 | 14 | 108 | 37.29 | 16.44 | 10 | 532.87 | 54.4 | 76 |
| 30mm | 33.19 | 56.92 | 16 | 110 | 43.19 | 13.44 | 10 | 654.58 | 60.8 | 85 |
