| ITEM NO.mm | WEIGHT/KG | WLL/T | B.L/T | Φ1 mm |
R mm |
D mm |
Φ2 mm |
H mm |
E mm |
| 6 | 0.5 | 1.12 | 4.48 | 22 | 110.5 | 10 | 34 | 19.5 | 28 |
| 7-8 | 0.8 | 2 | 8 | 25 | 136 | 12 | 46 | 24 | 34 |
| 10 | 1.55 | 3.15 | 12.6 | 32 | 171 | 15 | 56 | 28.5 | 44 |
| 13 | 3.2 | 5.3 | 21.2 | 40.5 | 208.5 | 19.5 | 69 | 20 | 52 |
| 16 | 5.74 | 8 | 32 | 56 | 257.5 | 22 | 86 | 50.5 | 60 |
| 20 | 8.5 | 12.5 | 50 | 64.5 | 275 | 27 | 100 | 55 | 81 |
| 22 | 13 | 15 | 60 | 70 | 320 | 30 | 98 | 67 | 82 |
| 26 | 18 | 21.2 | 84.8 | 80 | 363 | 34 | 110 | 24 | 110 |
| 32 | 44.5 | 31.5 | 126 | 105 | 472 | 45 | 166 | 97 | 168 |
