| ITEM NO.in | WEIGHT/KG | WLL/T | B.L/T | A mm |
B mm |
| 3/8X2″ | 0.11 | 0.5 | 3 | 10 | 50 |
| 1/2X2″ | 0.21 | 1 | 6 | 13 | 50 |
| 5/8X3″ | 0.46 | 1.5 | 9 | 16 | 76 |
| 5/8X3-5/16″ | 0.5 | 1.5 | 9 | 16 | 84 |
| 3/4X3″ | 0.67 | 2 | 12 | 19 | 76 |
| 3/4X4″ | 0.84 | 2.5 | 15 | 19 | 102 |
| 7/8X4″ | 1.2 | 3.5 | 21 | 22 | 102 |
| 7/8X5-1/2″ | 1.55 | 2.5 | 15 | 22 | 140 |
| 1X4″ | 1.59 | 5 | 30 | 25 | 102 |
| 1X5-1/2″ | 2.1 | 5 | 30 | 28 | 140 |
| 1-1/8X6″ | 2.87 | 5/6.5 | 30/39 | 32 | 152 |
| 1-1/4X5″ | 3.1 | 6 | 48 | 32 | 127 |
| 1-1/4X6″ | 3.6 | 8 | 48 | 32 | 152 |
| 1-1/4X10″ | 5.6 | 8 | 48 | 35 | 254 |
| 1-3/8X6″ | 4.5 | 8.6 | 51.6 | 38 | 152 |
| 1-1/2X8″ | 6.8 | 11 | 66 | 38 | 203 |
| 1-1/2X8-3/4″ | 7.32 | 11 | 66 | 38 | 222 |
| 1-1/2X10″ | 8.22 | 11 | 66 | 38 | 254 |
| 1-1/2X12″ | 17.8 | 11 | 66 | 38 | 305 |
| 1-3/4X9″ | 10.7 | 16 | 96 | 45 | 229 |
| 2X13-1/2″ | 19.05 | 20 | 120 | 50 | 343 |
