| SIZE |
WORKING LOAD LIMIT (TON)
|
PROOF LOAD (TON)
|
MINIMUM ULTIMATE LOAD (TON)
|
WEIGHT EACH (KG)
|
DIMENSION (MM) | |||||
| (IN) | (MM) | A | C | E | E1 | G | ||||
| 1/4-5/16 | 6-8 | 1.18 | 2.36 | 4.13 | 1.65 | 210 | 42 | 445 | 575 | 9.9 |
| 5/16-3/8 | 8-10 | 2.45 | 6 | 12 | 4.7 | 365 | 65 | 588 | 759 | 12.7 |
| 3/8-1/2 | 10-13 | 4.18 | 8.36 | 15 | 5.1 | 365 | 65 | 603 | 768 | 16.5 |
| 1/2-5/8 | 13-16 | 5.9 | 11.8 | 20.9 | 7.18 | 365 | 65 | 690 | 860 | 18.5 |
