| 规格 | A | B | C | D | F | 承重/个 | kg/个 |
| M3*30 | 3 | 15 | 33 | 5 | 5.8 | 15 | 0.0038 |
| M4*40 | 3.93 | 19.7 | 40.7 | 6.1 | 5 | 54 | 0.008 |
| M5*50 | 4.9 | 25.18 | 50.2 | 8.1 | 7 | 90 | 0.015 |
| M6*60 | 5.8 | 28.9 | 60.5 | 9.4 | 7.8 | 135 | 0.026 |
| M7*70 | 6.84 | 34.7 | 70 | 11.2 | 8 | 150 | 0.041 |
| M8*80 | 7.82 | 40.3 | 80.3 | 12 | 11 | 181 | 0.07 |
| M9*90 | 8.84 | 44.5 | 89.45 | 13 | 12 | 245 | 0.09 |
| M10*100 | 9.74 | 49.5 | 100.8 | 16 | 12 | 295 | 0.122 |
| M11*120 | 10.81 | 58 | 120.8 | 18 | 14 | 355 | 0.185 |
| M12*140 | 11.73 | 68.5 | 140.5 | 20.3 | 23 | 431 | 0.252 |
| M13*160 | 12.79 | 80.49 | 160.3 | 22.7 | 33.4 | 525 | 0.33 |
| M14*180 | 13.8 | 88.5 | 180 | 28 | 30 | 550 | 0.48 |
